Description

SR9080
High-Performance Bipolar Surround Speaker

Thank you for choosing the Definitive Technology BP9000 Bipolar Surround Speakers. These compact, high-quality bipolar speakers are intended primarily for use as a rear or side speakers. In addition, they can also be used as front “effects” speakers in multichannel DSP systems. The lifelike soundfield and flexible placement make this speaker an excellent addition to any room.
Our engineers have spent many years in developing this product. In order to ensure that you experience the finest performance possible, we encourage you to take a moment to fully read this owner’s manual and familiarize yourself with the proper installation and setup procedures for your SR surround speakers.

Product Highlights:

• Bipolar speaker design with wide sound dispersion for enveloping surround effects
• Balanced dual surround system (bdss) driver technology places rubber surrounds on both the outer and inner edges of each speaker cone for improved control and clarity
• Lleft and right speaker arrays each include a: 4-1/2″ bdss mid/woofer and a 1″ annealed aluminum dome tweeter with silk surround
• Frequency response: 40-40,000 hz
• Sensitivity: 92 db
• Impedance: compatible with 8-ohm outputs
• Recommended amplifier power: 20-200 watts
• One set of 5-way binding posts
• Keyhole slot for wall mounting
• High-gloss black finish on top and bottom caps with cloth grille-wrapped enclosure
• 9″W x 15-11/16″H x 6-1/16″D
• Warranty: 3 years

Features And Specs

• Enclosure : Bass Reflex
• Bipole Or Dipole : Bipole
• Tweeter : Dome
• Midrange Size (Inches) : N/a
• Connector Type : 5-way Post
• Power Range : 20-200
• Sensitivity : 92 Db
• Impedance (Ohms) : 8
• Frequency Response : 40-40k Hz
• Height (Inches) : 15 11/16
• Width (Inches) : 9
• Depth (Inches) : 6 3/16
• Mounting Bracket Included : Keyhole
• Warranty : 3 Years
